PRODUCT DESCRIPTION
Stainless Steel Round Bar — Machining Stock & Structural Supply
ZEMSS supplies stainless steel round bar in hot-rolled, cold-drawn, and turned-and-polished conditions from certified mill stock. Available from 6mm diameter up to 300mm, across a wide range of grades from standard austenitic 304 and 316L through to duplex 2205, precipitation hardening 17-4PH, and martensitic 410 for wear-resistant applications.
Each bar is supplied with a mill test report (MTR) confirming grade, heat number, chemical composition, and mechanical properties to ASTM A276 or EN 10088-3. Cut-to-length, rough-turned (turned-and-peeled), and centreless ground bar are available from the same facility, reducing raw material preparation time before CNC machining.
Product Specifications
| Parameter | Specification |
|---|---|
| Grades | 304 · 304L · 316 · 316L · 2205 Duplex · 17-4PH · 410 · 430 (other on enquiry) |
| Standard | ASTM A276 · ASTM A564 (17-4PH) · EN 10088-3 · JIS G4303 |
| Diameter Range | 6mm – 300mm (larger diameters as forgings on enquiry) |
| Length | Standard 3,000–6,000mm · cut-to-length available |
| Condition | Hot-rolled (HR) · Cold-drawn (CD) · Turned & polished (T&P) · Centreless ground |
| Tolerance | HR: h11 · CD: h9 · Ground: h6–h8 (to standard) |
| Surface | Bright (cold-drawn) · Pickled (hot-rolled) · Ground (precision) |
| MOQ | From 1 bar or 5 kg · no minimum surcharge |
| Lead Time | Stock sizes: 5–10 days · special grades / sizes: 15–30 days |
Grade Selection Guide
| Grade | Key Feature | Typical Application |
|---|---|---|
| 304 / 304L | General-purpose austenitic. Good machinability and weldability. | Shafts, pins, general machined parts, food handling components |
| 316 / 316L | Molybdenum addition — superior chloride and acid resistance. | Marine, chemical, pharmaceutical, and food contact machined parts |
| 2205 Duplex | ~2× yield strength vs 316L. Excellent pitting resistance. | Pump shafts, valve stems, structural pins in corrosive environments |
| 17-4PH | Precipitation hardening. High tensile strength (up to 1,310 MPa). Corrosion resistant. | High-strength fasteners, aerospace components, shafts requiring high hardness |
| 410 | Martensitic. Hardenable by heat treatment. Moderate corrosion resistance. | Wear-resistant parts, cutlery, valve components, shafts in non-aggressive media |
Key Properties
- Machinability — Austenitic grades (304, 316L) machine cleanly with sharp tooling. Work hardening is managed through correct feed/speed selection. 17-4PH in H900 condition is more machinable than annealed; 410 machines well in annealed state.
- Cold-drawn dimensional accuracy — Cold-drawn bar achieves h9 tolerance as standard, significantly tighter than hot-rolled material. Preferred for bar stock where close sliding or running fits are needed without intermediate grinding.
- Centreless ground precision — Centreless ground bar achieves h6–h7 tolerance and Ra ≤ 0.8µm surface finish. Used directly as shaft stock or precision dowel without further machining in many applications.
- High-strength options — 17-4PH in H900 condition achieves UTS ≥ 1,310 MPa and yield strength ≥ 1,170 MPa — comparable to alloy steel, with significantly better corrosion resistance. Enables smaller section sizes in high-load applications.
Applications
- Shafts & spindles — Pump shafts, agitator shafts, conveyor drive shafts, centrifuge spindles
- Fasteners & studs — CNC-machined bolts, threaded studs, coupling pins in chemical and food environments
- Valve components — Valve stems, seats, and bodies for chemical, pharmaceutical, and food process valves
- Machined parts — Flanges, nozzles, fittings, bushings, and custom machined components from solid bar stock
- Structural pins & dowels — Structural connections in stainless frameworks, hinge pins, pivot points
- Food handling — Conveyor rollers, guide pins, product contact parts in food processing machinery
Why Source from ZEMSS
- Wide grade and diameter range — 304 through 17-4PH and 410, 6mm to 300mm, from one supplier. Simplifies procurement across a project.
- In-house CNC machining — Bar stock machined to your drawing at the same facility. Supply raw bar or receive finished components — same lead time, one vendor.
- ISO triple certification — ISO 9001 / 14001 / 45001, certified by China Classification Society (CCS), IAF-recognised.
- Cut-to-length service — Bar cut to blanking lengths before dispatch. Reduces machining shop material handling and saw time.
- Export experience — Regular shipments to Europe, North America, and Southeast Asia. FOB Tianjin or EXW Taiyuan.
How to Order
To prepare your quotation, provide the following information:
- Grade: 304, 316L, 2205, 17-4PH, 410, or other
- Condition: hot-rolled, cold-drawn, turned & polished, or ground
- Diameter (mm) and length per piece
- Standard: ASTM A276, ASTM A564 (17-4PH), or EN 10088-3
- Quantity (bars or kg)
- Drawing or machining specification if CNC parts required
- Destination port and Incoterm (FOB / EXW)
We respond with a quotation and lead time within 2 business hours during UTC+8 working hours.
