Stainless Steel Channel Bar

Stainless steel channel bar (C-section and U-section) for structural, cable management, and fabrication applications. Available in 304 and 316L. Web height 30–200mm, flange 15–75mm. Conforms to ASTM A276 / EN 10088-3. Hot-rolled and cold-formed sections. Cut-to-length, drilled, and punched available.

MOQ: 1 bar or from 20 kg — no minimum surcharge
Mill test report (MTR) included with every order
ISO 9001 / 14001 / 45001 certified facility
Lead time: stock sizes 5–10 days · special sizes 10–25 days

<!–

Inquire About This Product

Description
Reviews (0)

PRODUCT DESCRIPTION

Stainless Steel Channel Bar — C-Section & U-Section Supply

ZEMSS supplies stainless steel channel bar (C-channel and U-channel sections) for structural framing, cable management systems, conveyor rails, and industrial fabrication. Produced by hot rolling or cold forming to ASTM A276 and EN 10088-3, each bar is traceable to heat number and supplied with a mill test report (MTR) confirming grade, chemical composition, and mechanical properties.

Grade 304 is specified for standard indoor and sheltered applications. Grade 316L is used in food processing, pharmaceutical, coastal, and chemical environments where chloride exposure or aggressive cleaning chemicals would cause premature corrosion in 304 steel.

Product Specifications

Parameter	Specification
Grades	304 (UNS S30400) · 316L (UNS S31603)
Standard	ASTM A276 · EN 10088-3 · JIS G4303
Section Type	C-channel (parallel flange) · U-channel (tapered flange) · Cold-formed strut channel
Web Height	30mm – 200mm
Flange Width	15mm – 75mm
Thickness	3mm – 12mm depending on section size
Length	Standard 6,000mm · custom cut-to-length available
Condition	Hot-rolled, annealed, pickled · cold-formed (for strut/framing sections)
MOQ	From 1 bar or 20 kg · no minimum surcharge
Lead Time	Stock sizes: 5–10 days · special sections: 10–25 days

Key Properties

Open section efficiency — C-section provides high bending stiffness-to-weight ratio in the web direction. The open face allows easy access for bolting, cable routing, or bracket attachment without drilling through a closed section.
Hygienic design compatibility — U-channel orientation (open face upwards or downwards) accommodates cove-welded joints with no hidden crevices. Critical in food and pharmaceutical fabrication where crevice corrosion and bacteria entrapment must be eliminated.
Strut channel for flexible installation — Cold-formed slotted strut channel (Unistrut-compatible profile) allows bolt-in-slot adjustment without drilling. Used in pipe support systems, cable trays, and equipment mounting.
Weldable to all standard stainless grades — TIG or MIG welded using matching filler. Pre-cut, pre-drilled, or pre-punched at our facility to reduce on-site fabrication time.
No coating required — Stainless steel channel does not require paint, galvanising, or powder coat. Long-term maintenance-free performance in corrosion-rated environments.

Applications

Cable tray & conduit support — Channel runs for electrical cable management in food, pharma, chemical, and offshore facilities
Structural framing — Machine bases, equipment supports, mezzanine purlin, wall bracketry
Conveyor systems — Guide rails, side guards, and frame members in food processing conveyor lines
Hygienic shelving — Open-profile shelving systems in GMP cleanrooms and food preparation areas
Drainage & gutter systems — Channel section used as gutter body in linear drainage installations
Pipe support systems — Slotted strut channel for adjustable pipe clamp and support assemblies

Why Source from ZEMSS

Mill-direct traceability — All channel bar sourced from certified mills with full heat-number records. MTR provided as standard.
Cut and drill service — Cut-to-length, drilled hole patterns, and slot punching available from the same facility. Reduces on-site fabrication labour.
ISO triple certification — ISO 9001 / 14001 / 45001, certified by China Classification Society (CCS), IAF-recognised.
MOQ from 1 bar — No minimum order surcharges. Sample lengths available.
Export experience — Regular shipments to Europe, North America, and Southeast Asia. FOB Tianjin or EXW Taiyuan.
